Trailer type

The thermal efficiency owes its excellent performance to Maxi-CUBE’s unique ‘cast to gauge’ wall construction that produces correctly-sized panels without the need to cut or destroy important surface cells.

Main Applications: Temperature sensitive freight such as ice cream, frozen meats and chilled produce.

All Maxi-CUBE Classic Freezer trailers are backed by Freighter Group’s national dealer and service support network.

ENQUIRE NOW

Key Specifications (Nominal)

Specification Image

Length 13,540mm

Specification Image

Performance-Based Standard (PBS)

Configurations available

Specification Image

3 year warranty

  • Length: 13,540mm
  • Overall Height: 4,300mm
  • Internal Length: 13,190mm
  • Internal Width: 2,426mm
  • Internal Height: 2,675mm

Various dimensions are available upon request

  • Full width skid plate
  • Stainless steel rear corner castings
  • Stainless steel external lock-rod door hardware
  • Full length chassis
  • Double rear doors
  • Fully-moulded door seal
  • Your choice of preferred body mounted refrigeration plant
  • High profile or flat distribution aluminium floors
Configuration: Available in Lead, Tag, B-Double and Road Train combinations. To find out how we can help you with the right solution for your business, contact your nearest Freighter Group dealer.

Features

  • Classic vans feature a full chassis bumper to skid plate providing maximum strength and longer body life with no reduction in payload
  • A light weight full width skid plate and optimised front wall design significantly reduce the trailer’s overall tare weight
  • Wall foam panels are extruded to size. Providing maximum thermal insulating properties
  • Composite, steel and aluminium floor construction results in lower tare mass
  • Cast extruded insulated flooring is superior to spray on alternatives and comes with galvanised steel backing for protection from damage
  • Full steel rear frames protect and reinforce the rear of the trailer against forces present in repeated docking operations
  • Full width lead-in plate prevents snags when coupling at different angles, reducing chance of damage

Options

  • Roller doors
  • Side doors
  • Meat hanger configuration
  • Horizontal double loader system
  • Belly lockers
  • Road train provision
  • Recessed logistics track
  • Multi temperature zones
  • Stainless steel floor plate
  • Vertical double loader system
  • Various suspension options, drum or disc
  • Additional internal lights
  • Additional clearance lights in compliance with ADR
  • Roof track lamps
  • Double loader box
For a comprehensive list of options, contact your Freighter Group dealer to find out more.
